18w solar tile Solar Power Roof Tiles shingle pv solar module factory Customized For home pv solar system Luxury Villa

Detail Information

Place of Origin:

Guangdong,China

Product Name:

SunPower Cell Solar Tile

Mounting Type:

Roof Mounting

Solar Panel Type:

SUNPOWER

Size:

518*183*36mm

Solar Cell:

SunPower Cell

Output Voltage (V):

18v

Output Frequency:

50hz

Work Time (h):

Certificate:

CE ROHS

Application:

Roof Home Solar System

System Type:

On Grid Roof

Warranty:

1year

Customized Product:

Yes

Packaging Details:

corton box for flexible solar panel for RV camping boat super light solar panel

Supply Ability:

1000 Piece/Pieces per Month

Highlight:

Product Description

18w 161mm SunPower Cell Bificial Solar Tile For Home Roof Home Solar System Exterior Roof Solar Tiles

Product Description

We provide two models for this product.

Model No.	eRigid M18W solar tile	eRigid M16.5W solar tile
Product Name	18w solar tile Solar Power Roof Tiles shingle pv solar module factory Customized For home pv solar system Luxury Villa	Bificial PERC cell mono solar tile
Maximum Power[Wp]	18	16.5
Solar Cell	USA SunPower solar cell 161mm	Bificial mono perc solar cell 158.75
Cell Array[Pcs]	1*3	1*3
Cell Efficiency	22.60%	22.50%
Size[mm]	51818336mm	51818336mm
Max Power Voltage Vmp[V]	1.8	1.74
Max Power Current Imp[A]	10.00	9.48
Open Circuit Voltage Voc[V]	2.12	2.05
Short Circuit Current Isc[A]	10.80	10.24
Net.Weight[kg]	0.2	0.2
Power tolerance[%]	±3%	±3%
NOCT[℃]	45±2	45±2
Operating Temperature[℃]	-40/+85	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.41	-0.41
Temperature Coefficient Voc[[%/℃]	-0.32	-0.32
Temperature Coefficient Isc[[%/℃]	0.04	0.04
Maximum System Voltage[V]	600 V	600 V
Certification	CE ROHS	CE ROHS
Solar tile frame	Yellow,for big order,can customize colour	Yellow,for big order,can customize colour
Frame/Backsheet	solar panel is frameless+ETFE	solar panel is frameless+ETFE
Jbox,Cables,Connection	PV-XC502 Jbox+0.9m cable	PV-XC502 Jbox+0.9m cable
Diode	Yes,1 pcs bypass diode	Yes,1 pcs bypass diode
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Package	100pcs per carton,plywood pallet or wooden case
