25%Customized Mono Semi Flexible Solar Panel For Bike 100W 110W 120W 150W 180W solar modules manufacturers energy system

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE ROHS

Product Name:

Light Weight Solar Panel

Cell Size:

158x158mm

Type:

PERC,IBC,Customized Solar Panel

Panel Dimensions:

350*950*4.5mm

Panel Efficiency:

25%

Warranty:

1 Year

Solar Cell:

Monocrystalline Solar Cell

Certificate:

CE ROHS ISO9001

Packaging Details:

Carton

Supply Ability:

5000sets/month

Highlight:

Product Description

25%Customized Mono Semi Flexible Solar Panel For Bike 100W 110W 120W 150W 180W solar modules manufacturers energy system

Why choose us?

Leading brand efficiency solar cell HPBC up to 25%;

Factory direct at lowest price at same quality level;

Engineer good service fast design,specification,sampling etc.

factory

Model No.	eGo S100M	eGo S110M	eGo S120M	eGo S150M	eGo S180M

Product Name	semi flexible solar panel	semi flexible solar panel	semi flexible solar panel	semi flexible solar panel	semi flexible solar panel
Maximum Power[Wp]	100	110	120	150	180
Solar Cell	Monocrystalline solar cell	Monocrystalline solar cell	Monocrystalline solar cell	Monocrystalline solar cell	Monocrystalline solar cell
Cell Array[Pcs]	3*12	3*12	3*12	4*9	4*9
Cell Efficiency	21.70%	21.70%	21.70%	21.70%	21.70%
Size[mm]	51010903	51011903	51012953	66012103	66014253
Max Power Voltage Vmp[V]	20.26	20.26	20.26	20.26	20.26
Max Power Current Imp[A]	4.94	5.43	5.92	7.40	8.88
Open Circuit Voltage Voc[V]	24.01	24.01	24.01	24.01	24.01
Short Circuit Current Isc[A]	5.33	5.86	6.40	8.00	9.60
Net.Weight[kg]	1.7	1.8	2	2.2	2.4
Power tolerance[%]	±5%	±5%	±5%	±5%	±5%
NOCT[℃]	45±2	45±2	45±2	45±2	45±2
Operating Temperature[℃]	-40/+85	-40/+85	-40/+85	-40/+85	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.43	-0.43	-0.43	-0.43	-0.41
Temperature Coefficient Voc[[%/℃]	-0.34	-0.34	-0.34	-0.34	-0.32
Temperature Coefficient Isc[[%/℃]	0.05	0.05	0.05	0.05	0.04
Maximum System Voltage[V]	1000 V	1000 V	1000 V	1000 V	1000 V
Maximum Reverse Current[V]	10A	10A	20A	20A	20A
Certification	CE ROHS	CE ROHS	CE ROHS	CE ROHS	CE ROHS
Surface/Backsheet	ETFE/white plastic
Maximum bend radius(θ)	20°
Cables and Connectors	PV-XC502 Jbox IP65,0.9m cable and 1 pair of MC4 connector
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes	round corner R10,with eyelets
Package	1pcs/Polyethylene foam(EPE Foam),then in 1 carton box
