230w Mono PERC Solar Cell Foldable Portable Solar Panels suitcase blanket For Motorhome portable power generator battert

230w Mono PERC Solar Cell Foldable Portable Solar Panels suitcase blanket For Motorhome portable power generator battert

Brand Name:	AHONY
Model Number:	eMobi Fab 4*57.5w
MOQ:	10 pieces
Price:	$168.00/pieces 10-99 pieces
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	20000 Piece/Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE ROHS

Type:

Foldable Customized Solar Panel

Size:

548*658*70mm

Cell Size:

166mmx166mm

Panel Efficiency:

24%

Application:

Camper Retailer Motorhome

Solar Cell:

Mono,Perc Solar Cell,A Grade Cell

Warranty:

1 Year

Certificate:

CE ROHS

Port:

Shenzhen

Packaging Details:

1pcs/Polyethylene foam(EPE Foam),then in 1 carton box

Supply Ability:

20000 Piece/Pieces per Month

Highlight:

Foldable Portable Solar Panels For Motorhomes

230w Mono PERC Solar Cell

Foldable Mono PERC Solar Cell

Product Description

Hot Sale Portable Solar Panels Foldable 230w Solar Charging Kit Mono PERC Solar Cell For Camper Retailer Motorhome

Company Information

230w Mono PERC Solar Cell Foldable Portable Solar Panels suitcase blanket For Motorhome portable power generator battert 0

factory

eMobi FM series uses mono PERC solar cells portable solar panels foldable 230w solar kit mono PERC solar cell

High efficiency solar cell 24%

ultralight material fabric

waterproof

small size and more foldable

For outdoor,emergency medical care,camping,RV etc

More power ouput inner parallel string

Model No.	eMobi F4x57.5w
Product Name	230w Mono PERC Solar Cell Foldable Portable Solar Panels suitcase blanket For Motorhome portable power generator battert
Maximum Power[Wp]	230
Solar Cell	A grade mono 166 9BB cells
Cell Efficiency	24%
Folded Size[mm]	54865870
Open Size[mm]	548235412
Max Power Voltage Vmp[V]	20.88
Max Power Current Imp[A]	11.02
Open Circuit Voltage Voc[V]	24.22
Short Circuit Current Isc[A]	11.68
Net.Weight[kg]	9/9.5
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.3
Temperature Coefficient Voc[[mV/℃]	-1.74mV
Temperature Coefficient Isc[mA/℃]	0.05
Maximum System Voltage[V]	200 V
Certification	CE ROHS
