100w Flexible Mono Solar Panel RV System Semi Flex Monocrystalline Pv Module

Detail Information

Place of Origin:

Guangdong, China

Cell Size:

158.75mmx158.75mm

Type:

PERC, Customized Solar Panel

Panel Dimensions:

510*1035*2mm

Panel Efficiency:

23%

Warranty:

1 Year, 1 Year

Product Name:

100W Solar Panel Flexible Solar Panel

Solar Cell:

Monocrystalline Solar Cell

Application:

Boat

Max Bend Angle:

60degree

Certificate:

CE ROHS ISO

Port:

Shenzhen

Packaging Details:

carton box

Supply Ability:

6000 Piece/Pieces per Month

Highlight:

Product Description

AHONY 100w Mono Flexible Solar Panel Max Bend 65degree Hight Efficiency Solar Cell Solar Pv Module Rv System Semi Flexi

Product Description

Model No.	eGo S100M
Product Name	semi flexible solar panel
Maximum Power[Wp]	100
Solar Cell	Monocrystalline solar cell
Cell Array[Pcs]	3*12
Cell Efficiency	23%
Size[mm]	51010352
Max Power Voltage Vmp[V]	20.26
Max Power Current Imp[A]	4.94
Open Circuit Voltage Voc[V]	24.01
Short Circuit Current Isc[A]	5.33
Net.Weight[kg]	1.7
Power tolerance[%]	±3%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.43
Temperature Coefficient Voc[[%/℃]	-0.34
Temperature Coefficient Isc[[%/℃]	0.05
Maximum System Voltage[V]	1000 V
Maximum Reverse Current[V]	10A
Certification	CE ROHS
Surface/Backsheet	ETFE/white plastic
Maximum bend radius(θ)	60°
Cables and Connectors	PV-XC502 Jbox IP65,0.9m cable and 1 pair of MC4 connector
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes	round corner R10,with eyelets
Package	1pcs/Polyethylene foam(EPE Foam),then in 1 carton box
