products details

Home Products

HPBC Back Contact 25.8% High Efficiency Solar Modules 220W Aluminum Frame Glass Panel Solar for Home System Installation

Brand Name:	AHONY/OEM
Model Number:	eRigid M225W
MOQ:	2-10pcs
Price:	0.35usd/watt
Payment Terms:	D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	3000 Piece/Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong

Certification:

CE; ROHS

Application:

On/Off Grid Solar System

Product Name:

Glass Solar Panel

Keyword:

High Efficiency Solar Panel

Solar Cell:

Longi HPBC Solar Cells

Frame:

Anodized Aluminium Alloy

Junction Box:

IP67

Certificate:

CE ROHS

Glass:

3.2mm Tempered Low Iron Glass

Connector:

MC4

Weight:

11kg

Packaging Details:

2pcs/ in 1 carton box

Product Description

Product Specification

Model No.	eRigid M225W
Product Name	Rigid glass solar panel
Maximum Power[Wp]	225w
Solar Cell	Longi HPBC solar cells
Cell Efficiency	25.8%
Size[mm]	600170030
Max Power Voltage Vmp[V]	40
Max Power Current Imp[A]	6.95
Open Circuit Voltage Voc[V]	46.80
Short Circuit Current Isc[A]	7.37
Net.Weight[kg]	10.5
Power tolerance[%]	0 to +3%
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.3
Temperature Coefficient Voc[[%/℃]	-0.26
Temperature Coefficient Isc[[%/℃]	0.05
Maximum System Voltage[V]	1000 V
Cables and Connectors	IP67 Jbox,0.7m 4.0m㎡ cable+MC4

Deeple customization:

lLogo customization:

Label Logo Customization: Put your company logo on the label.

Logo Lamination: Laminnate your company logo in the front of the panel.

lPackaging customization:

Print your company logo on the packaging carton box.

Gifted box.

lMaximum power customization:

Power range from 1-650W.

lType customization:

We could make standard type, bificial type, and provide color and frameless type.

Sample service:

We encourage our customers to try our products! Maximum number of samples per request: 1-9 pieces.

Company Profile:

AHONY POWER was founded in Shenzhen, southest China nearby Hongkong, Dongguan,Huizhou. Our team have more than 13 years solar experience, including producing, marketing, R&D. AHONY owns 4 official issued solar patents,1 of which is invention patent. We've managed under ISO quality system,products are certified by CE, ROHS, SGS, IEC. Product range is: ETFE PET fibreglass flexible solar panel,semi rigid solar module,glass solar panel, foldable solar kit.Both regular cells and USA SunPower cells. For every product offered by AHONY, we have strict producing process,quality inspection process and testing process. AHONY is dedicated to clean energy-solar technology innovation, ultralight solar panel technology, environmental friendly solar products, lighting products, power products etc.
