Potovoltaic Glass Solar Panel 200w Monocrystalline 60 Cell Solar Module

Brand Name:	oem
Model Number:	eRigid M200w
MOQ:	10 Piece
Price:	$0.42/watts 100-499 watts
Supply Ability:	20000 Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Product Name:

Perc Glass Solar Panel Mono 200w

Panel Dimensions:

1110*992*40mm

Panel Efficiency:

22.60%

Solar Cell:

PERC Mono Solar Cell

Cell Size:

158*158

Type:

Standard Solar Panel

Junction Box:

IP67 Rated

Feature:

Smart Charging IC

Voltage:

25.52

Certificate:

CE ROHS

Warranty:

5 Years

Port:

Shenzhen

Packaging Details:

1pcs/Polyethylene foam(EPE Foam),then in 1 carton box

Supply Ability:

20000 Pieces per Month

Highlight:

Potovoltaic Glass Solar Panel

Glass Solar Panel 200w

Monocrystalline 60 Cell Solar Module

Product Description

Potovoltaic Solar Panel 200w Monocrystalline 60cells For Home Solar System On Grid Solar System

Product Description

Monocrystalline solar panel uses A grade bifacial PERC solar cells,with cell efficiency 0ver 21.3%,the latest cell technology,the Jbox are waterproof IP65,cables are with UV resistanct which is suitable for outdoor.

Model No.	eRigid M200w
Product Name	bifacial perc solar panel mono 200w back contact cell for RVs boats cottages and industrial systems caravans vacation home
Maximum Power[Wp]	200
Solar Cell	A grade mono solar cell 4BB 5BB
Cell Array[Pcs]	6*12
Cell Efficiency	22.60%
Size[mm]	111099240
Size[inch]	21.3*56.9
Max Power Voltage Vmp[V]	25.52
Max Power Current Imp[A]	5.88
Open Circuit Voltage Voc[V]	30.11
Short Circuit Current Isc[A]	6.35
Net.Weight[kg]	8.6
Power tolerance[%]	±3%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/K]	-0.3
Temperature Coefficient Voc[[%/K]	-1.74mV
Temperature Coefficient Isc[[%/K]	0.05
Maximum System Voltage[V]	1000 V
Maximum Reverse Current[V]	20A
Certification	CE ROHS
Surface/Backsheet	Glass/silver frame/white backsheet
Cables and Connectors	Jbox IP65,2bypass diode,0.9m*4mm2 cable and 1 pair of MC4 connector
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Package	1pcs/carton box and plywood pallet
