115W ETFE Semi Flexible Solar Panel for Marine Boats Yachts

Brand Name:	AHONY or Customer's own brand
Model Number:	eMarvel 115W
MOQ:	4pcs
Price:	$151.8usd/pieces 4-50 pieces
Payment Terms:	D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	5000 Piece/Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong

Certification:

CE ROHS ISO9001 SGS

Application:

Marine

Product Name:

Semi Flexible Solar Panel

Type:

ETFE Semi Flexible Solar Panel

Certificate:

CE ROHS ISO9001 SGS

Solar Cell:

Sunpower Solar Cell

Weight:

5kg

Junction Box:

IP67 Waterproof

Cell Type:

SunPower Maxeon Cells

Warranty:

2 Years

Power:

115W

Packaging Details:

1pcs/Polyethylene foam(EPE Foam),then in 1 carton box

Supply Ability:

5000 Piece/Month

Highlight:

115W ETFE marine solar panel

semi flexible boat solar panel

ETFE yacht solar panel

Product Description

Product Specification

Model No.	eMarvel 115W
Product Name	Semi-rigid solar panel
Maximum Power[Wp]	115w
Solar Cell	SunPower Maxeon Gen III
Cell Efficiency	24.4%
Size[mm]	55010904mm
Max Power Voltage Vmp[V]	19.6
Max Power Current Imp[A]	6.12
Open Circuit Voltage Voc[V]	23.13
Short Circuit Current Isc[A]	6.61
Net.Weight[kg]	5kg
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.3
Temperature Coefficient Voc[[%/℃]	-1.74mV
Temperature Coefficient Isc[[%/℃]	0.05
Maximum System Voltage[V]	200 V
Cables and Connectors	4.0m㎡, bare at end

l Non-Stop Green Solar Powered: Equipped with high photoelectric conversion rate Sunpower solar cells, can provide uninterrupted power supply for the yacht or boat.

l HIGH EFFICIENCY: SunPower Maxeon Gen III, 24.4% high efficiency for power supply.

l WIDELY COMPATIBILITY: It is applicable for house roof, RV, boat.
