510101530 Dimensions 100W Solar Panel Module for Solar Roof Tile on Boat Caravan RV

510101530 Dimensions 100W Solar Panel Module for Solar Roof Tile on Boat Caravan RV

Brand Name:	AHONY
Model Number:	eRigid M100w
MOQ:	1000 watts
Price:	$0.35/watts 1000-4999 watts

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Cell Size:

158*79.4

Type:

HJT

Panel Dimensions:

510*1015*30

Panel Efficiency:

24.2%

Warranty:

5years

Product Name:

Pv Solar Module 100w For Boat Caravan

Solar Cell:

A Grade Solar Cell Mono

Certificate:

CE ROHS ISO9001, CE ROHS ISO

Catagory:

Monocrystalline Solar Panels

Junction Box:

XC0802

Highlight:

100W Solar Panel Module

Boat Solar Panel Module

RV Solar Panel Module

Product Description

factory

510*1015*30 Dimensions 100W Solar Panel Module for Solar Roof Tile on Boat Caravan RV 0

Product Description

Model No.	eRigid M100W
Product Name	Rigid Glass Monocrystalline solar Panel
Maximum Power[WP]	100
Solar Cell	Mono A grade solar cell
Cell Array[pcs]	158.75*79.4
Cell Efficiency	3*12
Size[mm]	24.20%
Size[inch]	510101530
Max Power Voltage Vmp[V]	21.60
Max Power Current Imp[A]	4.63
Open Circuit Voltage Voc[V]	25.42
Short Circuit Current Isc[A]	4.88
Net.Weight[kg]	6.20
Power tolerance[%]	±3%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/K]	-0.41
Temperature Coefficient Voc[[%/K]	-0.32
Temperature Coefficient Isc[[%/K]	0.04
Maximum System Voltage[V]	1000 V
Certification	CE ROHS
Cables and Connectors	0.9m cable+MC 4 connector IP67Jbox

510*1015*30 Dimensions 100W Solar Panel Module for Solar Roof Tile on Boat Caravan RV 1

Our Services

510*1015*30 Dimensions 100W Solar Panel Module for Solar Roof Tile on Boat Caravan RV 3

Packaging & Shipping

Packaging Details: carton box for this pv solar module 100w High Efficiency Module Off Grid PV Power for Battery Charging Boat Caravan RV and Any Other Off Grid

Port: shenzhen

Picture Example:

Le Thank you for viewing our pv solar module 100w High Efficiency Module Off Grid PV Power for Battery Charging Boat Caravan RV and Any Other Off Grid,here kindly see details of our panels.

High module conversion efficiency. Ideal output: 500Wh per day (depending on the availability of sunlight). Bypass diodes minimize power drop caused by shade and ensure excellent performance in low-light environments.
Off-grid fully self powered systems as RV solar panels, Boat solar panels, and Marines solar panels
Withstand high wind (2400Pa) and snow loads (5400Pa); resistant aluminum frame which allows the panels last for a long time
12 Volts battery use
25-year transferable power output warranty; 5-year material and workmanship warranty
