Custom Outdoor Mono 12V Foldable Solar Panel 60W 80W 100W 200W 230W 300W 400W 18V

Detail Information

Place of Origin:

Guangdong, China

Cell Size:

166*166

Type:

PERC, Customized Solar Panel

Panel Dimensions:

548*658*70mm

Panel Efficiency:

22.5%

Warranty:

1 Year

Product Name:

EMobi Fab 4*57.5w

Cell Efficiency:

24.00%

Application:

Outdoor Camping Hiking RV

Solar Panel:

Folding Solar Panel

Power:

230w

Certificate:

CE ROHS

Port:

Shenzhen

Packaging Details:

carton box

Supply Ability:

3000 Piece/Pieces per Month

Highlight:

Product Description

Custom Outdoor 60w 80w 100w 200w 230w 300w 400w 18v Portable Folding Solar Panel 12V Mono Foldable Solar Panel For Campi

Model No.	eMobi Fab 4*57.5w
Product Name	magnetic handle folding solar kits
Maximum Power[Wp]	230
Solar Cell	A grade mono 166 9BB cells
Cell Efficiency	24.00%
Folded Size[mm]	54865870
Open Size[mm]	548235412
Max Power Voltage Vmp[V]	20.88
Max Power Current Imp[A]	11.02
Open Circuit Voltage Voc[V]	24.22
Short Circuit Current Isc[A]	11.68
Net./Gross Weight[kg]	9/9.5
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.3
Temperature Coefficient Voc[[%/℃]	-1.74mV
Temperature Coefficient Isc[[%/℃]	0.05
Maximum System Voltage[V]	200 V
Certification	CE ROHS
Handle	Magnetic
Suface/backsheet	PET+high density textile
Output 1-USB	5V-3A,9V-2A,12V-1.5A
Output 2-Type C	PD65w
Output 3-DC5521	19v 6A
Cable1	DC5525+1m cable+MC4
Cable 2	1m DC5525 to DC5525
Supporting Leg	Yes,3 legs
Eyelets	Yes,4pcs stainless steel
Selling point	1. Magnetic suction type automatic closing, light, with high-quality anti-UV handle,durable; 2.Charging both 6v 12v system,can connect to 24v system by string; 3.22.5% high efficiency cell; 4.waterproof textile.
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Packing size[mm]	570680100
Package	1pcs/bubble plastic bag,then in 1 carton box,5sets in a master carton
