350w Flexible Walk On Solar Panels Semi Rigid Saltwater Proof For Marine Boat Yacht

Detail Information

Place of Origin:

Guangdong, China

Product Name:

Semi Rigid Solar Module

Cell Type:

PERC

Cell Size:

158mm

Panel Dimensions:

1667.5*992*5

Panel Efficiency:

22.5%

Warranty:

2 Years

Feature:

Lightweight

Application:

Home Power System,Camping,Motorhome,marine

Certificate:

CE ROHS SGSsalt Mist IEC

Packaging Details:

1pcs/Polyethylene foam(EPE Foam),then in 1 carton box

Supply Ability:

6000 Piece/Pieces per Month

Highlight:

Product Description

350w Walk On Semi Rigid Solar Panel Saltwater Proof Marine Solar Panel For Boat Yacht Rv Nautic Ce IEC Charging Battery

Model No.	eMarvel M350w
Product Name	Semi Rigid Solar Panel(white back panel)
Maximum Power[Wp]	350
Solar Cell	A grade mono PERC cell(5.9watt/pcs solar cell)
Cell Array[Pcs]	6*10
Cell Efficiency	22.50%
Size[mm]	1667.59925
Max Power Voltage Vmp[V]	31.20
Max Power Current Imp[A]	11.22
Open Circuit Voltage Voc[V]	36.19
Short Circuit Current Isc[A]	11.89
Net.Weight[kg]	14.3
Power tolerance[%]	±5%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/K]	-0.252
Temperature Coefficient Voc[[%/K]	-0.227
Temperature Coefficient Isc[[%/K]	0.031
Maximum System Voltage[V]	100 V
Maximum Reverse Current[V]	IR<2A-0
Flame retardancy	UL94 VTM-0
Certification and test	CE,ROHS,SGS,IEC salt mist,High temp humidity test
Surface/Backsheet	Japan ETFE/white plastic
Maximum bend radius(θ)	5°
Cables and Connectors	JB010(Junction box is on the panel's front side),2m dual cores cable bare at end
Warranty[Years]	2
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes	round corner R10,with silicon back up holes
Package	2pcs/Polyethylene foam(EPE Foam),then in 1 carton box
