Bifacial Custom Flexible 150w Mono Solar Panel ETFE For Marine Yacht RV Solar System watt flexible solar panel for motor

Bifacial Custom Flexible 150w Mono Solar Panel ETFE For Marine Yacht RV Solar System watt flexible solar panel for motor

Brand Name:	AHONY/OEM
Model Number:	eGos 150w
MOQ:	4 pieces
Price:	$102.00/pieces 4-99 pieces
Supply Ability:	60000 Piece/Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE ROHS

Product Name:

HJT Cell Semi Flexible Solar Panel

Panel Dimensions:

670*1145*2mm

Cell Size:

158.75mmx158.75mm

Type:

HJT

Panel Efficiency:

23%

Warranty:

1years

Application:

RV,Boat,Home,Roof,Camping,Motorhome,marine

Junction Box:

IP67 Waterproof

Connector:

MC4 Compatible Connector

Certificate:

CE ROHS

Port:

Shenzhen

Packaging Details:

1pcs per carton box for the product Ultra Lightweight ETFE surface flexible solar panel 110w 120w 200w 240w 5BB mono solar cell for offroad camping.
We offer a wide range of package service,customize gift box,white box,match box for flexible solar panel

Highlight:

Bifacial Mono Solar Panel

150w Mono Solar Panel

ETFE Custom Flexible Solar Panels

Product Description

Bifacial Custom Flexible 150w Mono Solar Panel ETFE For Marine Yacht RV Solar System watt flexible solar panel for motor

Model No.	eGo S150M
Product Name	semi flexible solar panel Bifacial Custom Flexible 150w Mono Solar Panel ETFE For Marine Yacht RV Solar System watt flexible solar panel for motor
Maximum Power[Wp]	150
Solar Cell	HJT solar cell
Cell Array[Pcs]	4*9
Cell Efficiency	22.7%
Size[mm]	68011452
Max Power Voltage Vmp[V]	20.52
Max Power Current Imp[A]	7.31
Open Circuit Voltage Voc[V]	24.01
Short Circuit Current Isc[A]	7.71
Net.Weight[kg]	3.7
Power tolerance[%]	±5%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.43
Temperature Coefficient Voc[[%/℃]	-0.34
Temperature Coefficient Isc[[%/℃]	0.05
Maximum System Voltage[V]	1000 V
Maximum Reverse Current[V]	1A
Certification	CE ROHS
Surface/Backsheet	ETFE/white plastic
Maximum bend radius(θ)	60°
Cables and Connectors	PV-XC505 Jbox IP65,0.9m cable and 1 pair of MC16 connector
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes	round corner R10,with eyelets
Package	1pcs/Polyethylene foam(EPE Foam),then in 1 carton box
