50W 22V ETFE Black Flexible Solar Panel, ETFE Black Thin, Slim Semi-Flexible PERC Mono High Efficiency Solar Cells 12 Volt for Battery Charge Marine RV Campers Boats Tent

Detail Information

Place of Origin:

Dongguan

Certification:

CE;RoHS

Product Name:

50W Solar Panel Flexible Solar Panel

Certificate:

CE ROHS ISO

Warranty:

1 Year

Solar Cell:

Longi HPBC Solar Cells

Application:

Marine RV

Max Bend Angle:

60 DEGREE

Weight:

2.4kg

Junction Box:

IP67 Rated Waterproof

OEM Order:

Shape/Logo/Wattage

Power:

50w

Packaging Details:

1pcs/Polyethylene foam(EPE Foam),then in 1 carton box

Supply Ability:

5000 Piece/ per Month

Product Description

Model No.	eGo S50W
Product Name	Semi-flexible solar panel
Maximum Power[Wp]	50w
Solar Cell	Longi HPBC solar cell
Cell Efficiency	25.8%
Size[mm]	4056303
Max Power Voltage Vmp[V]	22.5
Max Power Current Imp[A]	2.32
Open Circuit Voltage Voc[V]	26.33
Short Circuit Current Isc[A]	2.46
Net.Weight[kg]	2.4
NOCT[℃]	0 to +3%
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.3
Temperature Coefficient Voc[[%/℃]	-0.6
Temperature Coefficient Isc[[%/℃]	0.05
Maximum System Voltage[V]	100v
Cables and Connectors	Jbox IP67 XC502, 0.9m 2.5m㎡+MC4
