Foldable 22w Solar Panel IPX4 Waterproof Dual USB Solar Charger For Camp Hike RV

Detail Information

Place of Origin:

Guangdong, China

Product Name:

Potovoltaic Panel Foldable Solar Blanket

Cell Size:

158x158mm

Type:

PERC,Customized Solar Panel

Panel Dimensions:

200*290*28mm

Panel Efficiency:

23%

Connector:

Battery Clips

Style:

Leisure

Main Use:

Charge 12v Battery 9v 6v 12v

Use:

Lithium Battery Charger 12v Solar Panel Kit

Warranty:

1 Year

Certificate:

CE,ROHS,ISO9001

Packaging Details:

carton box for 22w portable USB solar charger

Highlight:

Product Description

22w Foldable Solar Panel With Smart Charge Dual USB(5V/4A Overall) IPX4 Waterproof Camp Hike Rv Portable Solar Panel Cha

Higher Solar Conversion Efficiency: PERC Solar Panels is the most durable panels at present, whose conversion efficiency can reach 23%. If clouds blocking the sun, this solar charger can detect intelligently the sunlight and restart to charge your electronic in 30s when there are enough sunlight. This folding solar charger is easy to carry for any outdoor activities such as camping, climbing, fishing etc.
Exclusive Smart IC Technology: With the built-in intelligent chip, our solar phone charger detects your device then deliver its fastest possible charging speed( Single maximum output up to 5V/2.4A, dual maximum outputs is up to 5V/4A). Dual-port applys to all the 5V Android devices and 5V powered apple devices. Note: We don't provide the lightning cable for Apple devices.
Special PET Polymer Surface: Industrial-strength PET polymer fabric protects your portable solar panel and your devices from occasional rain or wet fog. IPX4 waterproof level, but the USB ports and ammeter are not water-resistant, so keep them away from water while using. The pocket with a zip will keep your devices safe and clean while camping.
Easy to Use: Please unfold four solar panels under direct sunlight in the open air( No cloud and no shadow), then connect your device to the usb port with your certificated cable. 4 carabiners allow you to hook your solar charger everywhere convenient to get solar access.

Product Description

Model No.	eMobi F22W
Product Name	USB Solar Charger-regular
Maximum Power[Wp]	22
Solar Cell	A grade mono perc cell
Cell Array[Pcs]	12*3
Cell Efficiency	23.00%
Folded Size[mm]	20029028
Open Size[mm]	59829012
Max Power Voltage Vmp[V]	8.10
Max Power Current Imp[A]	2.72
Open Circuit Voltage Voc[V]	9.56
Short Circuit Current Isc[A]	2.93
Net.Weight[kg]	0.583
Output Voltage[V]	5/9/12
Port 1-USB	quick charge+MPPT 5V3A,9V2A,12V1.5A
Port 2-USB2	5V 3A
Colour	black+yellow
Certification	CE ROHS
Surface/Backsheet	PET,PU waterproof
Solar panel waterproof	IP65
Jbox Waterproof	IP30
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Eyelet	silver colour nickel coated copper,4pcs
Package	1pcs/carton box
Selling points	1.high efficiency sunpower cell; 2.much better weak light performance. 3.high performance workmanship.4.quick charge QC3.0.
