Light Rigid Solar Panel Glass 360w Monocrystalline Solar Panel For Electric Bike

• [High Conversion Efficiency] 360w monocrystalline solar panel for on grid solar system 360wwatt ideal output: 1800Wh per day (depending on the availability of sunlight). The surface is made of tempered glass, water resistant, snow resistant and resistant to small hail. The diodes are pre-installed in the junction box, a pair of 24" cables with MC4 connectors are automatically equipped, and 4 holes at the rear for quick installation.
• [Low-Cost Manufacturing] Long-term installation sites (such as roofs, RVs, street lights, outdoor, ships, islands, etc.) are applicable. It has a service life of more than 25 years and is 5 times that of ordinary flexible solar panels. This is the best choice for motorcycles and families. It has a very high cost performance and is the best choice for home energy investment.
• [Quality Assurance] Solar monocrystalline panel 150w. Waterproof, advanced packaging materials, multi-layer sheet lamination, improve battery performance and long service life. Durable and good heat dissipation. Corrosion-resistant aluminum frame for outdoor use.
• [Upgrade Service] solar panel monocrystalline photovoltaic panel solar 12v/18v. If you have any questions about the product, please let us know and we will refund all your money. So you can be sure that you are receiving safe, efficient, high quality equipment.

Thank you for reading our solar module 250w 260w 300w 360w 60cell 72cell a grade solar panel,please send us the enquiry our sales representative will contact you soon!

​

• Model No.	eRigid M360W
  Feature	high efficiency solar panel
  Product Name	360 watt solar panel mono 72cell 36v a grade solar cell for on grid system home system power plant 24v solar system
  Maximum Power[Wp]	360
  Solar Cell	PERC mono high efficiency A grade solar cell solar module
  Cell size[mm]	182*60.67mm
  Cell Array[Pcs]	6*24
  Cell Efficiency	22.7%
  Size[mm]	1135*1570*40mm
  Max Power Voltage Vmp[V]	41.76
  Max Power Current Imp[A]	8.63
  Open Circuit Voltage Voc[V]	48.44
  Short Circuit Current Isc[A]	9.15
  Net.Weight[kg]	16
  Power tolerance[%]	±3%
  NOCT[℃]	45±2
  Operating Temperature[℃]	-40/+85
  Temperature Coefficient Pmax[%/℃]	-0.41
  Temperature Coefficient Voc[[%/℃]	-0.32
  Temperature Coefficient Isc[[%/℃]	0.04
  Maximum System Voltage[V]	1000 V
  Certification	CE ROHS
