Mono 135W Glass Solar Panel For Building Customizable Solar Roof Tile

Detail Information

Place of Origin:

Guangdong, China

Product Name:

Light 135W Solar Panel To Use For Electric Bike

Cell Size:

182*91mm

Type:

PERC,Customized Solar Panel

Panel Dimensions:

590*1165*35mm

Panel Efficiency:

22.7%

Warranty:

1 Year

Solar Cell:

182 PERC Solar Cell

Application:

Home Use Off Grid Marine Solar Panel

Module:

Rigid Mono Solar Cell For Home Solar System

Certificate:

CE ROHS

Port:

Shenzhen

Packaging Details:

1pcs/Polyethylene foam(EPE Foam),then in 1 carton box

Supply Ability:

3000 Piece/Pieces per Month

Highlight:

Product Description

Top Quality Solar Panel Glass Facade For Building Glass Solar Panel 135v Transparent Customizable Solar Roof Tile

Product Description

Model No.	eRigid M135w
Product Name	light 135W solar panel to use for home solar system for electric bike
Maximum Power[Wp]	135
Solar Cell	182 PERC Solar Cell
Cell Array[Pcs]	3*12
Cell Efficiency	22.70%
Size[mm]	590116535
Solar Cell Size[mm]	182*91
Max Power Voltage Vmp[V]	20.88
Max Power Current Imp[A]	6.47
Open Circuit Voltage Voc[V]	24.22
Short Circuit Current Isc[A]	6.85
Net.Weight[kg]	7.70
Power tolerance[%]	±3%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/K]	-0.3
Temperature Coefficient Voc[[%/K]	-1.74mV
Temperature Coefficient Isc[[%/K]	0.05
Maximum System Voltage[V]	1000 V
Maximum Reverse Current[V]	20A
Certification	CE ROHS
Surface/Backsheet	Glass/silver frame/white backsheet
Cables and Connectors	Jbox IP65,2bypass diode,0.9m*4mm2 cable and 1 pair of MC4 connector
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
