160w Solar Flexible Panels

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE ROHS

Product Name:

160w Semi Flexible Solar Panel

Cell Size:

125mmx125mm

Panel Dimensions:

550*1470*3mm

Panel Efficiency:

24.4%

Type:

Customized Solar Panel

Solar Cell:

SunPower Maxeon Gen III Back Contact Cell

Application:

Travling Camping Rv Home Boat Yacht

Warranty:

1 Year

Certificate:

CE ROHS ISO

Packaging Details:

1pcs/Polyethylene foam(EPE Foam),then in 1 carton box

Highlight:

Product Description

170w Sunpower Solar Panel Flexible Solar Panel Hight Efficiency Solar Cell For Motorcycle Auto Camping Rv Home Boat Yach

Product Description

Model No.	eGo S160w
Product Name	Semi-Flexible Solar Panel
Maximum Power[Wp]	160
Solar Cell	SunPower Maxeon Gen III Back Contact Cell
Cell Array[Pcs]	4*11
Cell Efficiency	24.4%
Size[mm]	55014703
Max Power Voltage Vmp[V]	26.9
Max Power Current Imp[A]	5.95
Open Circuit Voltage Voc[V]	31.4
Short Circuit Current Isc[A]	6.31
Net.Weight[kg]	6.55
Power tolerance[%]	0 to 3%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/K]	-0.3
Temperature Coefficient Voc[[%/K]	-1.74mV
Temperature Coefficient Isc[[%/K]	0.05
Maximum System Voltage[V]	100 V
Maximum Reverse Current[V]	10A
Certification	CE ROHS
Surface/Backsheet	Japan ETFE/white plastic
Maximum bend radius(θ)	30°
Cables and Connectors	JB030,2m cable no connector
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes	round corner R10,with eyelets
Package	1pcs/Polyethylene foam(EPE Foam),then in 1 carton box
