Semi Flexible Solar Panels For Sailboats 120w Mono Half Cut Solar Panels

Brand Name:	AHONY or OEM
Model Number:	eGo S120w HF
MOQ:	10 pieces
Price:	$125.00/pieces 10-99 pieces
Supply Ability:	1000 Piece/Pieces per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Type:

Semi Flexible Solar Panel

Cell Size:

125mmx125mm

Panel Dimensions:

540x1085x3mm

Panel Efficiency:

19.62%

Feature:

High Performance Shade Power Produce Max

Certificate:

CE ROHS ISO9001

Warranty:

1 Year

Application:

Sailboat,yacht,

Style:

Luxury

OEM Order:

Yes

Packaging Details:

carton box for

Supply Ability:

1000 Piece/Pieces per Month

Highlight:

Flexible Solar Panels For Sailboats

120w Mono Half Cut Solar Panels

Flexible Mono Half Cut Solar Panels

Product Description

Best Shade Perfomance Semi Flexible Solar Module 120w For Sailboat Parallel Bypass Higher Power Half Cut Flexible Solar

The half cut semi flexible solar panel series reduce the current of each panel.It has much more advantage over traditional semi flexible solar panel.

1. Less current more Power

The half cut reduce the current each cell and avoid heating problem,reduce the risk of hot dot ,heating etc,in this way,the panel power output is 2-3wattages over regular panels;

2. Inner parallel design,voltage drop less when shade,produce more power

It has more obvious performance on sailboat,which has half shade most of time.

The inner parallel design.

Model No.	eGo S120w
Product Name	Semi-Flexible Solar Panel
Maximum Power[Wp]	120
Solar Cell	Back Contact Cell
Cell Array[Pcs]	4*8
Cell Efficiency	24.40%
Size[mm]	540x1085x3
Max Power Voltage Vmp[V]	20.1
Max Power Current Imp[A]	5.97
Open Circuit Voltage Voc[V]	23.12
Short Circuit Current Isc[A]	6.33
Net.Weight[kg]	4.7
Power tolerance[%]	±3%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/K]	-0.3
Temperature Coefficient Voc[[%/K]	-1.74mV
Temperature Coefficient Isc[[%/K]	0.05
Maximum System Voltage[V]	100 V
Maximum Reverse Current[V]	IR<2A-0
Certification	CE ROHS
Surface/Backsheet	Japan ETFE/white PET
Maximum bend radius(θ)	30°
