120w Solar Flexible Panels IP67 Monocrystalline Marine Solar Panels For RV Camping Boat

Detail Information

Place of Origin:

Guangdong, China

Product Name:

120W Flexible Solar Panel

Cell Size:

158.75mmx158.75mm

Type:

PERC,Customized Solar Panel

Panel Dimensions:

540*1060*3mm

Panel Efficiency:

22.6%

Warranty:

1year

Solar Cell:

Mono 156*156 Cell

Application:

Car,Boat,Yacht,

Junction Box:

IP67

Certificate:

Ce Rohs

Packaging Details:

corton box for flexible solar panel for RV camping boat super light solar panel

Supply Ability:

10000 Piece/Pieces per Month

Highlight:

Product Description

120w Mono Flexible Solar Panel For RV Camping Boat Phantasie Billig Tragbare Luftkhler

Product Description

Model No.	eGo S120M
Product Name	semi flexible solar panel
Maximum Power[Wp]	120
Solar Cell	Monocrystalline solar cell
Cell Array[Pcs]	3*12
Cell Efficiency	21.70%
Size[mm]	51012953
Max Power Voltage Vmp[V]	20.26
Max Power Current Imp[A]	5.92
Open Circuit Voltage Voc[V]	24.01
Short Circuit Current Isc[A]	6.40
Net.Weight[kg]	3.2
Power tolerance[%]	±5%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.43
Temperature Coefficient Voc[[%/℃]	-0.34
Temperature Coefficient Isc[[%/℃]	0.05
Maximum System Voltage[V]	1000 V
Maximum Reverse Current[V]	20A
Certification	CE ROHS
Surface/Backsheet	ETFE/white plastic
Maximum bend radius(θ)	20°
Cables and Connectors	PV-XC502 Jbox IP65,0.9m cable and 1 pair of MC4 connector
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes	round corner R10,with eyelets
Package	1pcs/Polyethylene foam(EPE Foam),then in 1 carton box
