Waterproof Mono 300w longi solar Semi Flexible Solar Panel system product energy vendorsPV For Rv Camp House Roof

Brand Name:	AHONY Power
Model Number:	eGo S300M
MOQ:	10 pieces
Price:	$195.00/pieces 10-99 pieces
Payment Terms:	Western Union, T/T, D/P, D/A, L/C, MoneyGram
Supply Ability:	1000 Piece/Pieces per Month

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE ROHS

Product Name:

Semi Flexible Solar Panel

Cell Size:

158.75mmx158.75mm

Panel Dimensions:

24.4%

Panel Efficiency:

20%

Weight:

4.6

Junction Box:

JB022 Jbox On Front

Solar Cell:

HJT HCF 9BB 158mm Solar Cell

Packaging Details:

20pcs/carton box or 60pcs/wooden case

Supply Ability:

1000 Piece/Pieces per Month

Highlight:

Product Description

AHONY Photovoltaic Panel Waterproof 300w Mono Semi Flexible Solar Panel HCF Cell For Rv Camp Solar Module House Roof Gol

Product Description

Model No.	eGo S300M
Product Name	Waterproof Mono 300w longi solar Semi Flexible Solar Panel system product energy vendorsPV For Rv Camp House Roof
Maximum Power[Wp]	300
Solar Cell	Monocrystalline solar cell
Cell Array[Pcs]	6*9
Cell Efficiency	24.2%
Size[mm]	100014903
Max Power Voltage Vmp[V]	31.32
Max Power Current Imp[A]	9.58
Open Circuit Voltage Voc[V]	36.64
Short Circuit Current Isc[A]	10.34
Net.Weight[kg]	4.6
Power tolerance[%]	±3%
NOCT[℃]	45±2
Operating Temperature[℃]	-40/+85
Temperature Coefficient Pmax[%/℃]	-0.43
Temperature Coefficient Voc[[%/℃]	-0.34
Temperature Coefficient Isc[[%/℃]	0.05
Maximum System Voltage[V]	1000 V
Maximum Reverse Current[V]	10A
Certification	CE ROHS
Surface/Backsheet	ETFE/white plastic
Maximum bend radius(θ)	60°
Cables and Connectors	PV-XC502 Jbox IP65,0.9m cable and 1 pair of MC4 connector
Standard Test Conditions	STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes	round corner R10,with eyelets
Package	1pcs/Polyethylene foam(EPE Foam),then in 1 carton box
